Long Back up Pure Sine Wave DC-AC Solar Power Inverters with Bypass Voltage 1-12KW

Name: Long Back up Pure Sine Wave DCAC Solar Power Inverters with Bypass Voltage 112KW
Brand: SOROTEC
Price: 1 USD

Buy cheap Long Back up Pure Sine Wave DC-AC Solar Power Inverters with Bypass Voltage 1-12KW product

Brand Name : SOROTEC

Model Number : IG3115CS 1-12KW

Certification : CE,ROHS,RSO9000

Place of Origin : Shenzhen,China

MOQ : 5PCS

Price : Negotiable

Payment Terms : Western Union, T/T, L/C

Supply Ability : 5000PCS Per Month

Delivery Time : Within 15-30days after receiving your 30% TT deposit

Packaging Details : Standard Exported Cartons and Pallets

Product : Off-Grid Inverter

Model : IG3115CS 1-12KW

Capacity : 1-12KW

Waveform : Pure sine wave

Low Frequency : Yes

DC Voltage : 12V/24V/48V/96V

Transfer Time : 10ms Typical

Output Power Factor : 0.9-1.0

With Solar Controller : Optional

Nominal Voltage : 230VAC, 120VAC(optional)

Frequency : 50/60HZ

Bypass Function : Yes

Support Generator input : Yes

Application : Air-conditioning,Fridge ,PC,TV.etc

Protection : Overload,short-circuit

Charging Method : 3-steps

Max Charge Current : 85Amp

OEM/LOGO : Allowed

Contact Now

1-12KW Long Back up Pure Sine Wave DC-AC Power Inverter with Bypass Voltage

IG3115CS Series Pure Sine Wave Output Inverter

Key Features:

1.Pure sine wave output
2.The charging current is big up to 85 Amp
3.Output power factor:s 0.9-1
4.Well accept generator’s output
5.Full automatical and silent operation
6.Automatically transfer between battery and line modes
7.Microprocessor control guarantees high reliability
8.Remote control function
9.Three-steps intelligent charging control to recharging time
10.Bypass and bypass voltage regulation function
11.Could be setting frequency by LCD display with color screen
12.Battery type and charge current can be select

Technical Specification of Pure Sine Wave Inverter IG3115CS Series:

MODEL	IG3115CS 1-12KW Pure Sine wave Output Inverter
	1KW	1.5KW	2KW	3KW	4KW	5KW	6KW	8KW	10KW	12KW
Input Wave form	Sine wave (utility or generator)
Nominal Voltage	230Vac (120Vac optional)
Low voltage trip	90v ±4% & 184v/154v ±4%
Low voltage re engage	100v ±4% & 194v/164v±4%
High voltage trip	140v ±4% & 253v ±4%
High voltage re engage	135v ±4% & 243v±4%
Nominal Input Frequency	50Hz/ 60Hz (auto detection)
Frequency range	47Hz~65Hz
Output Wave form	(Bypass mode)same as input
Efficiency on line transfer mode	≥95%+
Line transfer time	10ms Typical
Bypass without battery connected	Yes
Inverter specification/output
Output wave form	Pure sine wave
Output continuos power watts	1000	1500	2000	3000	4000	5000	6000	8000	10000	12000
Output continuos power VA	1000	1500	2000	3000	4000	5000	6000	8000	10000	12000
Power factor	0.9-1.0
Nominal Output Voltage rms	230Vac (120Vac optional)
Output Voltage regulation	+/- 10%rms
Output frequency	50Hz ± 0.3Hz or 60Hz ± 0.3Hz
Safety Certification	>88%
Surge ratings	3000	4500	6000	9000	12000	15000	18000	24000	30000	36000
Short circuit protection	Yes,fault after 1 secs
Inverter specification/input
Nominal input voltage	12V/24V/48V							48V/96V
Minimum start voltage	10V/20V/40V							80V
Low battery alarm	10.5V/21V/42V							84V
Low battery trip	10V/20V/40V							80V
High voltage alarm	16V/32V/64V							128V
Power saver	Same switched on/off on remote
Charger mode specification
Output voltage	Dependent on battery type
Charge current	0-85A MAX							70/35A	85/45A	100/50A
Battery initial voltage for start up	0-15.7v for 12v(2 for 24v;4 for 48v;*8 for 96v)
Over charge protection shutdown	15.7v for 12v(2 for 24v;4 for 48v;*8 for 96v)
Charger curves(4stage constant curren)	battery types
4 step digital controlled progressive charge
Battery type	Fast V Fast V(2 for 24v;4 for 48v)
Gel U.S.A	14 13.7
A.G.M. 1	14.1 13.4
A.G.M. 2	14.6 13.7
Sealed lead acid	14.4 13.6
Gel euro	14.4 13.8
Open lead acid	14.8 13.3
Calcium	15.1 13.6
De-sulphation	15.5 for 4 hrs
Remote control/RS232/USB	Yes. Optional

Long Back up Pure Sine Wave DC-AC Solar Power Inverters with Bypass Voltage 1-12KW

Full protection:

Protection for low battery voltage,over load,output short circuit and over- temperature Restrain surge interference,eliminate noise protection for thunder striking,provide the reliable power to the home appliances

Long Back up Pure Sine Wave DC-AC Solar Power Inverters with Bypass Voltage 1-12KW
